| Motor type | Permanent Magnet (PM) stepper motor | |
| Electrical Enclosure | IP | 40 |
| Connections | Flexible Leads 30 AWG, 200mm length; ends stripped 10 mm | |
| Life expectancy | 3 years in continuous operation | |
| Weight | g | 30 |
| Mounting | Any position by ears |
| Mechtex | Physical data | No load data | Data at Rated Torque | Stall | ||||||
| MODEL No. | Dia x height | Voltage | Speed | Current | Speed | Current | Torque | Power | Torque | Current |
| mm | V DC | RPM | mA | RPM | mA | cNm | W(out) | cNm | A | |
| BO2215 | 21*15 | 12 | 9350 | 55 | 5120 | 700 | 0.7 | 3.5 | 1.8 | 1.6 |
| 21*15 | 24 | 9280 | 26 | 5190 | 380 | 0.7 | 3.7 | 2 | 0.9 | |
